HP Compaq 2230s Specification

HP Integrated Module
with Bluetooth
Wireless Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
* The specifications for 802.11n draft 2.0 are draft specifications and are not final. If the final
specifications differ from the draft specifications, it may affect the ability of the notebook to
communicate with other 802.11n WLAN devices. In countries where n draft 2.0 is not allowed, this
capability is not enabled.
Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with
desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both
left and right control and alt keys, and 12 function keys. US and International key layouts are
available. Other features include an integrated numeric keypad, hotkeys for instant access to
power conservation, brightness, and other features, 19 mm x 19 mm key pitch (center-to-center
spacing), 2.5 mm stroke, and comfort-dished keycaps.
Touch-sensitive
controls
Touch-sensitive controls provide easy access to the following features: HP Info Center, HP
Presentation button, wireless on/off, mute, and volume up, volume down
Pointing device Touchpad with scroll zone, two pick buttons
Expansion card slots ExpressCard/34 slot Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes
Secure Digital slot Supports SD (Secure Digital), MMC (MultiMedia Card) cards
Storage Hard drives 120/160/250/320/500 GB 5400 rpm SMART SATA II
160 GB 7200 rpm SMART SATA II Hard Drive
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal
cycles. Up to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer
temporarily halts all data transfer and parks the hard drive when abrupt
motion is detected.
Fixed optical drives DVD-ROM Drive
DVD/CD-RW Combo Drive
DVD+/-RW SuperMulti DL LightScribe Drive
Blu-ray ROM DVD+/-RW SuperMulti DL Drive
NOTE: Optical drive available only with 1.8-inch hard drive.
QuickSpecs
HP Compaq 2230s Notebook PC
Standard Features
DA - 13106 Worldwide QuickSpecs — Version 7 — 1/8/2009 Page 5

HP Compaq 2230s Specifications

General

Processor model	-
Processor family	Intel® Celeron® M
Processor manufacturer	Intel
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	No
Total storage capacity	120 GB
Display surface	Gloss
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	4 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Type	PC
Modem speed	56 Kbit/s
Internal modem	Yes
Wireless technology	802.11a/b/g/n draft 2.0
Bluetooth version	2.0+EDR
Networking features	Marvell Ethernet (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	4
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
AC adapter power	65 W
Battery performance	37 W
Pointing device	Touchpad + Scroll zone
Country of origin	China

Weight and Dimensions

Depth	294 mm
Height	226 mm
Weight	1850 g
Height (front)	28 mm
