* Configurations of the Compaq 610 that are ENERGY STAR qualified are identified as Compaq 610 ENERGY
STAR on HP websites and on www.energystar.gov .
** EPEAT registration varies by country. See www.epeat.net for registration status by country.
EPEAT status listed above applies to U.S.
NOTE: For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
HP 90W AC Adapter Dimensions 5.00 x 1.97 x 1.1 in (12.7 x 5.0 x 2.9 cm)
Weight 0.82 lb (370 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.5 A at 90 VAC, 0.75 A at 180 VAC
Output Output power 90W
DC output 19.0V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals –
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF– over 200,000 hours at 25°C ambient condition.
QuickSpecs
Compaq 610 Notebook PC
Technical Specifications
DA - 13304 Worldwide — Version 7 — January 7, 2010 Page 13

HP Compaq 610 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
HDD speed	7200 RPM
HDD capacity	320 GB
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Compatible memory cards	SD
Number of HDDs installed	1
Stepping	M0
Tjunction	100 °C
FSB Parity	No
Processor cache	2 MB
Processor cores	2
Processor model	T5870
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T5000 Series
Processor socket	LGA 3647 (Socket P)
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	35 W
Processor core voltage (AC)	1.075 - 1.175 V
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Operating system installed	Windows XP Professional
Motherboard chipset	Intel GME965 Express
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	3 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory slots (available)	0
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows XP Windows 7
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Audio system	HD
Pointing device	Touchpad + Scroll zone
Cabling technology	10/100Base-T(X)
Networking features	Fast Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Password protection type	HDD
Battery capacity	47 Wh
Battery life (max)	5 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China
Processor code	SLAZR
Processor ARK ID	37034
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	245 mm
Width	370.8 mm
Height	32 mm
Weight	2475 g
