HP Compaq 610 User Manual

Chipset Models with integrated graphics:
Mobile Intel GLE960 Express Chipset with ICH8M, 533 MHz front side bus
or Mobile Intel GME965 Express Chipset with ICH8M, 800 MHz front side bus
Models with discrete graphics:
Mobile Intel PM965 Express Chipset with ICH8M, 800 MHz front side bus
Graphics Models with integrated graphics:
Mobile Intel Graphics Media Accelerator X3100, up to 384 MB shared system memory
Models with discrete graphics:
ATI Mobility Radeon HD 4330 graphics with 256 MB dedicated video memory and
HyperMemory support
Microsoft DirectX 10.1 (discrete),10 (integrated) capable
Display Internal 15.6-inch diagonal LED-backlit HD 16:9 widescreen anti-glare
(1366 x 768 resolution)
15.6-inch diagonal LED-backlit HD 16:9 widescreen BrightView
(1366 x 768 resolution)
15.6-inch diagonal CCFL-backlit HD 16:9 widescreen BrightView
(1366 x 768 resolution)
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 1600 x 1200 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
Memory Standard 512 MB, 1 GB, or 2 GB 667 MHz or 800 MHz DDR2 SDRAM*;
two SODIMM slots supporting dual channel memory
Maximum Upgradeable to 4 GB** total memory
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
* Models with Mobile Intel GLE960 Express Chipset use this memory at a maximum memory speed of 533
MHz. Models with Mobile Intel GME965 or Mobile Intel PM965 Express Chipset use this memory at a
maximum memory speed of 667 MHz.
** 4 GB maximum requires Mobile Intel GME965 or PM965 Express Chipset.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or
Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.
QuickSpecs
Compaq 610 Notebook PC
Standard Features (availability may vary by country)
DA - 13304 Worldwide — Version 7 — January 7, 2010 Page 5

HP Compaq 610 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
HDD speed	7200 RPM
HDD capacity	320 GB
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Compatible memory cards	SD
Number of HDDs installed	1
Stepping	M0
Tjunction	100 °C
FSB Parity	No
Processor cache	2 MB
Processor cores	2
Processor model	T5870
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T5000 Series
Processor socket	LGA 3647 (Socket P)
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	35 W
Processor core voltage (AC)	1.075 - 1.175 V
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Operating system installed	Windows XP Professional
Motherboard chipset	Intel GME965 Express
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	3 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory slots (available)	0
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows XP Windows 7
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Audio system	HD
Pointing device	Touchpad + Scroll zone
Cabling technology	10/100Base-T(X)
Networking features	Fast Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Password protection type	HDD
Battery capacity	47 Wh
Battery life (max)	5 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China
Processor code	SLAZR
Processor ARK ID	37034
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	245 mm
Width	370.8 mm
Height	32 mm
Weight	2475 g
