HP Compaq 610 User Manual

Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. International key layouts are available. Other features include
an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and other
features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, comfort-dished keycaps,
and bright key legends for improved visibility in low light conditions.
Pointing device Touchpad with scroll zone, two pick buttons
Expansion Card Slots ExpressCard/34 slot Supports ExpressCard/34 (34 mm x 75 mm x 5 mm)
Secure Digital slot Supports SD (Secure Digital), and MultiMediaCard
Storage Hard drives 160/250/320 GB 7200 rpm SMART SATA II
160/250/320/500 GB 5400 rpm SMART SATA II
NOTE: Up to 15 GB is reserved for the system recovery software.
DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive.
Fixed optical drives DVD ROM Drive
DVD+/-RW SuperMulti DL LightScribe Drive
Interfaces ExpressCard/34 slot Supports ExpressCard/34
External Monitor One - VGA
External Microphone One
Headphone/Line out One
Power Connector One
RJ-11/modem (optional) One
RJ-45/Ethernet One
USB 2.0 Three
LED Status Indicators Six
Audio/Visual High Definition Audio support
Integrated mono speaker
Stereo headphone/line out
Stereo microphone in
Optional integrated 2MP webcam
QuickSpecs
Compaq 610 Notebook PC
Standard Features (availability may vary by country)
DA - 13304 Worldwide — Version 7 — January 7, 2010 Page 7

HP Compaq 610 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
HDD speed	7200 RPM
HDD capacity	320 GB
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Compatible memory cards	SD
Number of HDDs installed	1
Stepping	M0
Tjunction	100 °C
FSB Parity	No
Processor cache	2 MB
Processor cores	2
Processor model	T5870
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T5000 Series
Processor socket	LGA 3647 (Socket P)
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	35 W
Processor core voltage (AC)	1.075 - 1.175 V
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Operating system installed	Windows XP Professional
Motherboard chipset	Intel GME965 Express
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	3 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory slots (available)	0
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows XP Windows 7
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Audio system	HD
Pointing device	Touchpad + Scroll zone
Cabling technology	10/100Base-T(X)
Networking features	Fast Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Password protection type	HDD
Battery capacity	47 Wh
Battery life (max)	5 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China
Processor code	SLAZR
Processor ARK ID	37034
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	245 mm
Width	370.8 mm
Height	32 mm
Weight	2475 g
