Remove the system board:
1. Press the PC Card eject button (1) twice. The first press releases the PC Card eject button from the
PC Card slot. The second press releases the PC Card slot bezel from the PC Card slot. (The PC
Card slot bezel is partially ejected from the PC Card slot.)
NOTE: The PC Card slot bezel is included in the Plastics Kit, spare part number 443905-001.
2. Remove the PC Card slot bezel (2).
3. Disconnect the USB/Media Card Reader board cable (3) from the system board.
Component replacement procedures
93
