HP Compaq 6830s Specification

Memory Standard 667 MHz or 800 MHz DDR2 SDRAM; two slots supporting dual channel
memory
1024 MB or 2048 MB
Maximum Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same
size and speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we
recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system
will perform at the lower memory speed. Full availability of 4 GB or more of memory requires
Windows Vista Business 64-bit or Linux. With Windows 32-bit operating systems, the amount of
usable memory is dependent upon your configuration, so that above 3 GB all memory may not be
available due to system resource requirements.
Communications Marvell Ethernet (10/100/1000 NIC) *
56K V.92 modem **
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab
for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed
transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem
availability is subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless LAN options featuring support for the
latest industry standards. Integrated Bluetooth is also available (factory configurable only) and can
be combined with any of the supported wireless LAN options.
All 802.11 integrated
wireless LAN options
Wi-Fi certified *
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-
GTC, PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure
Intel WiFi Link 5100 Integrated support for 802.11a, b, g, and n draft 2.0 *
Up to 300 mbps data rate
Intel WiFi Link 5100 Integrated support for 802.11 a, b and g
Up to 54 mbps data rate
Broadcom 4322AGN
802.11a/b/g/draft-n Wi-
Fi Adapter
Integrated support for 802.11a, b, g, and n draft 2.0 *
Up to 300 mbps data rate
Broadcom 4312G
802.11b/g
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54 mbps data rate
HP Integrated Module
with Bluetooth
Wireless Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
* The specifications for 802.11n draft 2.0 are draft specifications and are not final. If the final
specifications differ from the draft specifications, it may affect the ability of the notebook to
communicate with other 802.11n WLAN devices. In countries where n draft 2.0 is not allowed, this
capability is not enabled (Intel 802.11a/b/g only).
QuickSpecs
HP Compaq 6830s Notebook PC
Standard Features
DA - 13057 Worldwide QuickSpecs — Version 4 — 8.22.2008 Page 5

HP Compaq 6830s Specifications

General

Stepping	M0
Tjunction	100 °C
FSB Parity	No
Processor cache	2 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T5000 Series
Processor socket	LGA 3647 (Socket P)
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Motherboard chipset	Intel® PM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	250 GB
Display diagonal	17 \
Display resolution	1440 x 900 pixels
Native aspect ratio	16:10
Internal memory	3 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	AMD Mobility Radeon HD 3430
Discrete graphics card memory	0.25 GB
Audio system	High Definition Audio
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Networking features	Gigabit Ethernet, WLAN
Operating system installed	Windows Vista Home Basic
Number of battery cells	8
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
Pointing device	Touchpad
Processor code	SLAZR
Processor ARK ID	37034
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	285 mm
Width	396 mm
Height	32 mm
Weight	2950 g
