HP Compaq 6830s Specification

Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with
desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both
left and right control and alt keys, and 12 function keys. US and International key layouts are
available. Other features include a full numeric keypad, hotkeys for instant access to power
conservation, brightness, and other features, 19.05 x 19.05 mm key pitch (center-to-center
spacing), 3.0 mm stroke, and comfort-dished keycaps.
Pointing device Touchpad with scroll zone, two pick buttons
Expansion card slots
ExpressCard/54 slot Supports ExpressCard/54 (54 mm x 75 mm x 5 mm) and
ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes
Media Card Reader Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,
Memory Stick Pro, Memory Stick Duo * , xD-Picture card
* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo
Card directly into your notebook could damage the memory card and/or notebook.
Storage Internal Storage Device 120/160/250 GB 5400 rpm SMART SATA II Hard Drive
120 GB 7200 rpm SMART SATA Hard II Drive
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal
cycles. Up to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer
temporarily halts all data transfer and parks the hard drive when abrupt
motion is detected.
Fixed optical drives Blu-ray ROM DVD+/-RW SuperMulti DL Drive
DVD+/-RW SuperMulti DL LightScribe Drive
DVD/CD-RW Combo Drive
DVD-ROM Drive
Interfaces ExpressCard/54 slot One (Supports ExpressCard/54 and ExpressCard/34)
External monitor One (VGA)
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
USB 2.0 Four
LED status indicators Seven
QuickSpecs
HP Compaq 6830s Notebook PC
Standard Features
DA - 13057 Worldwide QuickSpecs — Version 4 — 8.22.2008 Page 6

HP Compaq 6830s Specifications

General

Stepping	M0
Tjunction	100 °C
FSB Parity	No
Processor cache	2 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T5000 Series
Processor socket	LGA 3647 (Socket P)
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Motherboard chipset	Intel® PM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	250 GB
Display diagonal	17 \
Display resolution	1440 x 900 pixels
Native aspect ratio	16:10
Internal memory	3 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	AMD Mobility Radeon HD 3430
Discrete graphics card memory	0.25 GB
Audio system	High Definition Audio
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Networking features	Gigabit Ethernet, WLAN
Operating system installed	Windows Vista Home Basic
Number of battery cells	8
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
Pointing device	Touchpad
Processor code	SLAZR
Processor ARK ID	37034
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	285 mm
Width	396 mm
Height	32 mm
Weight	2950 g
