Power
Requires a 3.3-V auxiliary power rail on PCI express bus
Uses only one PCI express load (i.e., one grant/request pair), one shared IRQ, one electrical load
Chipset LSI SV92EX - Integrated PCI interface with 3.3-V tolerant buffers and CardBus support
Dimensions (L X H)
Complies with PCI express low profile specifications-6.7 x 2.3 in (17.0 x 5.8 cm) and supports high-
and low-profile brackets
Connection Single RJ-11 connector
Other Features
Digital line protection, call progress monitoring via on-board piezo device, support for high profile
and low profile brackets, PnP ID support
Safety
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950 (TUV, NEMKO, DEMKO, SEMKO); CE
Mark, EC 950 (TUV, NEMKO, DEMKO, SEMKO, CE mark
EMC FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN 61000-4-6, EN 61000-4-8
Telecom
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Other
The SV92EX device is packaged in a 32-pin micro leadless chip carrier (MLCC). The SV92EX is fully
compliant with the PCI Express revision 1.1 specification. WHQL approved; ASPM compliant.
QuickSpecs
HP Compaq 8100 Elite Series
Technical Specifications - Communications
DA - 13524 Worldwide — Version 27 — September 30, 2011 Page 31

HP Compaq 8100 Elite Series Specifications

General

Processor	Intel Core i5 or i7
Chipset	Intel Q57 Express
Memory	Up to 16 GB DDR3
Network	Integrated Intel 82578DM Gigabit Network Connection
Audio	Integrated High Definition Audio with Realtek ALC261 codec
Storage	250GB to 1TB HDD or 128GB SSD
Graphics	Integrated Intel HD Graphics or optional discrete graphics
Optical Drive	DVD-ROM
Operating System	Windows 7 Professional
Form Factor	Small Form Factor
USB Ports	10 USB 2.0 ports
Ports	VGA, DisplayPort
Power Supply	240W to 320W depending on form factor
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 1 PCI
