Drop (in box) 42 in (107 cm) on concrete, 16-drop sequence
Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
Ergonomic compliance ANSI HFS 100, ISO 9241-4, and TUVGS
Kit contents
Keyboard Installation Guide
Warranty Card Safety and Comfort Guide
HP PS/2 Standard Keyboard
Physical
characteristics
Keys
104, 105, 106, 107, 109 layout
(depending upon country)
Dimensions (L x W x H)
18.0 x 6.4 x 0.98 in
45.8 x 16.3 x 2.5 cm
Weight
2 lb
0.9 kg minimum
Electrical
Operating voltage + 5VDC ± 5%
Power consumption 50-mA maximum (with three LEDs ON)
System interface PS/2 6-pin mini din connector
ESD CE level 4, 15-kV air discharge
EMI – RFI Conforms to FCC rules for a Class B computing device
Microsoft® PC 99 – 2001 Functionally compliant
Mechanical
Languages 38 available
Keycaps Low-profile design
Switch actuation 55-g nominal peak force with tactile feedback
Switch life 20 million keystrokes (using Hasco modified tester)
Switch type Contamination-resistant switch membrane
Key-leveling mechanisms For all double-wide and greater-length keys
Cable length
6 ft
1.8 m
Microsoft PC 99 –2001 Mechanically compliant
Acoustics 43-dBA maximum sound pressure level
Operating temperature 50° to 122° F (10° to 50° C)
Non-operating temperature -22° to 140° F (-30° to 60° C)
Operating humidity 10% to 90% (non-condensing at ambient)
QuickSpecs
HP Compaq 8100 Elite Series
Technical Specifications - Input/Output Devices
DA - 13524 Worldwide — Version 27 — September 30, 2011 Page 47

HP Compaq 8100 Elite Series Specifications

General

Processor	Intel Core i5 or i7
Chipset	Intel Q57 Express
Memory	Up to 16 GB DDR3
Network	Integrated Intel 82578DM Gigabit Network Connection
Audio	Integrated High Definition Audio with Realtek ALC261 codec
Storage	250GB to 1TB HDD or 128GB SSD
Graphics	Integrated Intel HD Graphics or optional discrete graphics
Optical Drive	DVD-ROM
Operating System	Windows 7 Professional
Form Factor	Small Form Factor
USB Ports	10 USB 2.0 ports
Ports	VGA, DisplayPort
Power Supply	240W to 320W depending on form factor
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 1 PCI
