Total Memory Socket
Channel A Channel B
1 (black) 2 (white) 3 (white) 4 (white)
2 GB 2 GB unpopulated unpopulated unpopulated
4 GB
(dual channel)
2 GB unpopulated 2 GB unpopulated
8 GB
(dual channel)
2 GB 2 GB 2 GB 2 GB
16 GB
(dual channel)
4 GB 4 GB 4 GB 4 GB
USDT SFF CMT
Storage Drive Support
USDT SFF CMT
SDR ODD HDD MCR ODD HDD MCR ODD HDD
Quantity Supported 1 1 1 1 1 2 1 2 3
Position 1 2 3 1 2 1,3 3 1,2 4,5,6
Data Storage Drives
USDT SFF/CMT
160-GB Hard Disk Drives
HP 160GB 7.2K rpm SATA 3.0Gb/s 2.5” Hard Disk Drive X
HP 160GB 10K rpm SATA 3.0Gb/s 2.5” Hard Disk Drive
Includes 3.5” adapter
X
250-GB Hard Disk Drives
HP 250-GB 7.2K rpm SATA 3.0Gb/s 2.5” Hard Disk Drive X
HP 250-GB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive X
300-GB Hard Disk Drive
QuickSpecs
HP Compaq 8200 Elite Series
Standard Features and Configurable Components (availability may vary by country)
DA - 13879 North America — Version 36 — August 15, 2013 Page 11

HP Compaq 8200 Specifications

General

Power Supply	240W (SFF), 320W (MT)
Graphics	Intel HD Graphics
Operating System	Windows 7 Professional
Processors	Intel Core i3, i5, or i7
Memory	Four DIMM slots; Up to 32 GB DDR3 SDRAM
Optical Drive	DVD-ROM, DVD-RW
Audio	High Definition Audio
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, DisplayPort, VGA, serial, parallel, PS/2, audio in/out
Form Factor	Small Form Factor
Processor	Intel Core i3, i5, or i7
Storage	250GB
