Conventional PCI
Revision 2.3
5-volt
N/A
1 each
2.5” low profile
6.6” length
25W max. power
3 each
4.2” full height
6.6” length
25W max. power
PCI Express 2.0
N/A
1 each x1 slot
2.5” low profile
6.6” length
25W max. power
1 each x1 slot
4.2” full height
6.6” length
25W max. power
N/A
1 each x16 slot
2.5” low profile
6.6” length
25W max. power
1 each x16 slot
4.2” full height
6.6” length
75W max. power
(for single graphics card)
35W max. power
(for dual graphics cards)
N/A
1 each x16 slot
(wired as a x4)
2.5” low profile
6.6” length
25W max. power
1 each x16 slot
(wired as a x4)
4.2” full height
6.6” length
35W max. power
Bays
USDT
SFF
CMT
3.5” external
N/A
1 bay available for Media Card
Reader unless used for a
secondary hard drive
N/A
5.25” external
N/A
1 each
8.19” depth
2 each
8.19" depth
1 each
5.7" depth
Slim
1 each
N/A N/A
Secure Digital (SD) Reader
1 each
N/A N/A
Internal HDD Bays
1 each
2.5” drives
1 each
3.5” drives
3 each
3.5” drives
Controller
USDT
SFF
CMT
Hard Drive Controller
These systems provide up to four serial ATA (SATA) interfaces that support transfer rates up to 6.0
Gb/s (for ports 0 and 1, 3 Gb/s on all others) and RAID data protection functionality. These systems
can also support an external SATA (eSATA) device through an optional bracket/cable assembly (does
not apply to USDT).
SATA Interfaces
2 ea. SATA 3.0 2 ea. SATA 3.0
1 ea. SATA 2.0
1 ea. eSATA
2 ea. SATA 3.0
2 ea. SATA 2.0
1 ea. eSATA
Host SATA Controller
Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a description of
the hardware/software interface between system software and the host controller hardware.
QuickSpecs
HP Compaq 8200 Elite Series
Technical Specifications
DA - 13879 North America — Version 36 — August 15, 2013
Page 21
