HP Compaq Business Desktop dx2000 User Manual

HP 2-Button Scroll
Mouse (PS/2 or USB)
Scroll Wheel 8 mm
Maximum Rotation
Speed
30 mm/s
Switch Type Light force micro-switch
Switch Life 1 million operations
Mechanical Life Minimum 200,000 revolutions
Environmental Operating Temperature 50° to 122° F (10° to 50° C)
Non-operating
Temperature
-22° to 140° F (-30° to 60° C)
Operating Humidity 10% to 90% (non-condensing at ambient)
Non-operating
Humidity
20% to 80% (non-condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating
Vibration
4 g peak acceleration
Electrical Operating Voltage 5VDC ± 10%
Power Consumption 15mA
System Consumption PS/2 mini-din connector
or
USB Type-A plug connector
ESD CE level 4, 15 kV air discharge
EMI-RFI Conforms to FCC rules for a Class B
computing device
PC98 Functionally compliant
Mechanical Resolution 400 ± 20% DPI
Tracking Speed 10 in/s maximum
Acceleration 100 in/s
Switch Actuation 85 g nominal peak force
Switch Life 1,000,000 operations (using Hasco modified
tester)
Cable Length 2 m
PC98-99 Mechanically compliant
Regulatory Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BCIQ, C-Tick
QuickSpecs
HP Compaq Business Desktop dx2000 microtower
Technical Specifications - Input/Output Devices
DA - 11851 North America — Version 37 — March 21, 2007 Page 24

HP Compaq Business Desktop dx2000 Specifications

General

Optical Drive	CD-ROM, CD-RW, or DVD-ROM
Network	Integrated 10/100 Ethernet
Power Supply	250W
Processor	Intel Pentium 4 or Celeron
Storage	Up to 160 GB HDD
Operating System	Windows XP Professional
Audio	Integrated audio
Expansion Slots	3 PCI
Ports	USB 2.0, serial, parallel, VGA, audio
Graphics	Integrated Intel Extreme Graphics
