PCI High Speed 56K
Worldwide
Controllerless
WinModem
Data Transmission
High speed 56K modem technology speeds: 56,000 Kbps maximum
downstream data, controllerless
NOTE:
56 Kbps technology refers to download speeds only and
requires compatible modems at server sites. Other conditions may limit
modem speed. FCC limitations allow a maximum of 53 Kbps during
download transmissions.
Data Speeds
(Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/16,800/
14,400/12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards
ITU high speed 56K modem, ITU-T, V.34bis, V.22bis, V.22bis, V.21,
V.23, Bell 212A, and Bell 103
Fax Speeds
14,400/12,000/9,600/7,200/4,800/2,400/1,200/300 b/s
Fax Mode Capabilities
Group3 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2, Class 1
Error Correction and
Data Compression
V.44 (software upgradeable), 4.2bis, V.42 and MNP2-5
Power Management
APM and ACPI states D0, D1, D2, and D3; meets PCI 2.2 requirements
and PC'99 requirements
Upgradeability
Software driver upgradeable for high speed 56K modem and future
enhancements
Video
ITU-T V.80 video ready interface
Other
TIA/EIA 602 standard AT command set
ntegrated DTE interface with speeds of up to 115.2 Kbps, parallel
16550a UART-compatible interface
Optional ring wakeup signal
Operating Temperature
32° to 158° F (0° to 70° C)
Operating Humidity
20% to 90%, non-condensing
Power
Requires a 3.3-V auxiliary power rail on PCI bus
Uses only one PCI load (i.e., one grant/request pair), one shared IRQ,
one electrical load
Chipset
Agere Systems 1648C (Mars 3.2) - Integrated PCI interface with 5-V
tolerant buffers and CardBus support
Dimensions
(L X H)
Complies with PCI low profile specifications - 6.7 x 2.3 in (17.0 x 5.8 cm)
and supports high-and low-profile brackets
Connection
Dual, parallel RJ-11 support with auxiliary Tip/Ring connector
Other Features
Digital line protection, call progress monitoring via on-board piezo
device, transformer-based DAA design, support for high profile and low
profile brackets, PnP ID supports via external EEPROM
Safety
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950
(TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO,
DEMKO, SEMKO, CE mark
EMC
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN
61000-4-6, EN 61000-4-8
Telecom
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in India, Russia, Slovakia, Slovenia, Belarus, Brunei,
Croatia, Ecuador, Latvia, Lithuania, Morocco, Peru, Phillipines, Sri
Lanka, Ukraine, Malaysia (use DC132B or DC132C instead)
Health
Bare PCB material compliant to 94V-0 or better (marked as such),
Microsoft Windows Me health compliant
QuickSpecs
HP Compaq Business Desktop dx2000 microtower
Technical Specifications - Communications
DA - 11851 North America — Version 37 — March 21, 2007
Page 20
