Data Transfer Modes
ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA mode 2 (16.7
MB/s); ATA UltraDMA mode 0 (16.7 MB/s); ATA UltraDMA mode 1 (24
MB/s), mode 2 (33 MB/s); ATA UltraDMA Mode 3 44 Mbytes/s (default)
Cache Buffer
2 MB (minimum)
Startup Time
(single)
< 7 seconds (typical)
Startup Time
(multi-session)
< 30 seconds (typical)
Stop Time
< 4 seconds
Power
Source
Four-pin, DC power receptacle
DC Power Requirement
5 VDC ± 5% – 100 mV ripple p-p
12 VDC ± 5% – 200 mV ripple p-p
DC Current
5 VDC (< 1000 mA typical, < 1600 mA
maximum)
12 VDC (< 600 mA typical, < 1400 mA
maximum)
Total Drive Power
(standby mode)
< 2.5 Watt
Audio Output Level
0.7 Vrms (typical)
Configuration Jumper
Block
Master, slave, and cable select modes
Data Interface
Connector
40-pin, shrouded and keyed, flat ribbon
Environmental
(all conditions non-
condensing)
Temperature
(operating)
41° to 122° F (5° to 50° C)
Relative Humidity
(operating)
10% to 90%
Maximum Wet Bulb
Temperature
(operating)
86° F (30° C)
Certifications,
Approvals
MPC-3 compliant, multi-read requirements, ACA AS/NZS 3548, ANSI
C63.4-1992, ATAPI Spec SFF-8020, ATA Spec X3T9.2, CB Bulletin No.
92A, CSA C22.2 No. 950-1995, C.I.S.P.R. Pub 22, EMKO-TSE 207/94,
TUV or VDE EN60 950, EN60825-1, Microsoft PC2001 certification,
Microsoft Logo for Windows XP, 2000, and NT4
16X DVD+/-RW Drive
Height
5.25-inch, half-height, tray-load
Orientation
Either horizontal or vertical
Interface type
ATAPI/EIDE
Disc recording
capacity
8.5 GB DL or 4.7 GB standard
Dimensions
(W x H x D)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
Weight
(max)
2.6 lb (1.2 kg)
QuickSpecs
HP Compaq Business Desktop dx2000 microtower
Technical Specifications - Optical Storage
DA - 11851 North America — Version 37 — March 21, 2007
Page 32
