Integrated Graphics
Media Accelerator 3000
3D/2D Controller Microsoft DirectX® 9 based with support for Pixel Shader 2.0, 4:1 anisotropic
filtering, Gaussian texture filtering, shadow maps, volumetric textures,
double-sided stencil buffers, and 4 pixel pipes.
VGA Controller Integrated
Bus Type PCI Express™ x16 (If an external graphics card is installed in a PCI slot, the
internal graphics can be enabled or disabled using the system's BIOS setup
utility. If an external graphics card is installed in the PCI Express™ slot, the
internal graphics cannot be enabled).
RAMDAC Integrated, 400 MHz
Memory Graphics memory is shared with system memory. Graphics memory usage
varies depending on the amount of system memory installed and system load.
8 MB is pre-allocated for graphics use at system boot time. Additional memory
is allocated for graphics as needed using Intel's Dynamic Video Memory
Technology (DVMT), to provide an optimal balance between graphics and
system memory use.
System memory equal or greater than 512 MB
8 MB pre-allocated + 248 MB DVMT = max frame buffer of 256 MB
Controller Clock Speed 400 MHz
Overlay Planes Single overlay support with 5x3 filtering
Maximum Color Depth 32 bits/pixel
Maximum Vertical
Refresh Rate
85 Hz at up to 1920x1440, 85 Hz at 2048x1536. Varies with mode and
configuration. See table below.
Multi-display Support Support for one CRT via the motherboard's VGA connector. Support for an
additional DVI-D display via the optional DVI ADD2 card. Dual independent
displays and dual synchronous (Twin or Clone mode) displays are supported.
Graphics/Video API
Support
Microsoft DirectX®9, DirectXVA®, VMR9, GDI/GDI+; OpenGL® 1.4.
Resolutions Supported
1
Resolution Maximum Refresh Rate (Hz)
Analog Monitor Digital Monitor
640 x 480
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
1920 x 1080
1920 x 1200
1920 x 1440
2048 x 1536
85
85
85
85
85
85
85
85
85
60
60
60
60
60
60
60
60
60
1
Modes listed are supported with a single active display. The supported mode list for multiple active displays is a subset of this list.
Not all modes will support video playback and some supported modes may use software MC (motion compensation) rather than
hardware MC. Not all modes will support 3D acceleration depending on the system configuration (e.g., resolution selected, size of
frame buffer, number of installed memory modules, etc.).
NOTE: Other resolutions and refresh rates may be selectable but are not recommended.
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Graphics
DA - 12668 North America — Version 17 — May 21, 2008 Page 22

HP Compaq dx2300 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	Intel® Pentium® D
Processor frequency	1.6 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	800 MHz
Internal memory	0.5 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	1 x 0.5 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	160 GB
Platform	PC
Audio input	1
CD read speed	16 x
Mac compatibility	No
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Graphics card RAMDAC	400 MHz
Diskette drive memory	1.44 MB
USB 1.1 ports quantity	0
Audio formats supported	AAC, MP3, WAV, WMA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Non-operating relative humidity (non-condensing)	5 - 95 %
Discrete graphics card model	-
Maximum graphics card memory	0.256 GB
Operating system installed	Windows XP Professional
USB 2.0 ports quantity	8
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Power supply	250 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, VCCI

Weight and Dimensions

Depth	416 mm
Width	175 mm
Height	353 mm
Weight	9600 g
Package weight	14000 g
