Integrated Broadcom
NetXtreme Gigabit PCI-E
ethernet NIC
Connector RJ-45
Controller Broadcom 5782 PCI LAN Controller
Memory Integrated 96Kb frame buffer memory
Data rates supported 10/100/1000 Mbps
Compliance IEEE 802.1A, 802.1P, 802.1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,
802.3x flow control
Bus architecture PCI 2.2
Data path width 32-bit, 33/66 MHz bus interface
Data transfer mode Bus-master DMA
Hardware certifications FCC class B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark
for European Union
Power requirement 1.48 watts @ +3.3V AUX supply with 5V tolerance
Boot ROM support Yes
Network transfer rate 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T, 1000 Mbps
Environmental Operating temperature 32° to 131° F (0° to 55° C)
Operating humidity 85% at 131° F (55° C)
Dimensions 4.7 x 2.0 x 0.08 in (12 x 5 x 1.9 cm)
Management capabilities ACPI, WOL and DMI 2.0, PXE 2.0, WfM 2.0
Alerting ASF 1.0
Intel PRO/1000 MT Gigabit
PCI NIC
Connector RJ-45
Controller Intel 82540EM Gigabit Controller
Memory Integrated 96Kb frame buffer memory
Data rates supported 10/100/1000 Mbps
Compliance IEEE 802.1A, 802.1P, 802.1P, 802.1Q, 802.2, 802.3, 802.3AB and 802.3u
compliant, 802.3x flow control
Bus architecture PCI 2.2
Data path width 32-bit, 33/66 MHz bus interface
Data transfer mode Bus-master DMA
Hardware certifications FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union
Power requirement 1.48 watts @ +3.3V AUX supply with 5V tolerance
Boot ROM support Yes
QuickSpecs
HP Compaq Business Desktop dx6120 Series
Technical Specifications - Communications
DA - 12243 Worldwide — Version 21 — May 25, 2007 Page 29
