Data Transfer Modes PIO Mode 4 (16.6 MB/s); Multi-word DMA mode 2 (16.6 MB/s); UltraDMA Mode
3 (44.4 MB/s)
Power Source Four-pin, DC power receptacle
DC Power Requirement 5 VDC ± 5% – 100 mV ripple p-p
12 VDC ± 5% – 200 mV ripple p-p
DC Current 5 VDC – <800 mA typical, < 1000 mA maximum
12 VDC – < 870 mA typical
Audio Output Level 0.7 Vrms (typical)
Configuration Jumper
Block
Master, slave, and cable select modes
Data Interface Connector 40-pin, shrouded and keyed, flat ribbon
Environmental
(all conditions non-
condensing)
Temperature (operating) 41° to 122° F (5° to 50° C)
Relative Humidity
(operating)
10% to 85%
Maximum Wet Bulb
Temperature (operating)
86° F (30° C)
Certifications, Approvals MMC II support, multi-read certification, Microsoft WHQL certification, ACA
AS/NZS 3548 class B, CNS 13438, C.I.S.P.R. Pub 22, TUV or VDE EN60950, EN
55022, EN55024, SEMKO, NEMKO, DEMKO, FIMKO, EN 60825-1, UL 60950, and
CSA C22.2 60950-2000.
16X/48X DVD-ROM Drive Height 5.25-in, half-height
Interface Type ATAPI
Dimensions– External,
Excluding Bezel (W x H)
5.88 x 1.71 in (149.5 x 43.5 mm)
Disc Diameter 12 cm, 8 cm
Disc Thickness 1.2 mm
Track Pitch 1.6 µm (CD), 0.74 µm (DVD)
Disc Center Hole Diameter 15 mm
Disc Formats DVD-ROM (single and dual layer); DVD-video; DVD-R version 1.0 and 2.0; DVD-
RW version 1.0 and 1.1; DVD-R multi-border; DVD+RW; DVD+R, DVD+R DL ;
CD-ROM Mode 1 and 2; CD-DA; CD-ROM XA Mode 2, Form 1 and 2; CD-extra;
CD-text; CD-I Mode 2, Form 1 and 2; CD-I ready; video CD, CD-bridge; PhotoCD
(single and multi-session); CD-R; CD-RW
Disc Capacity DVD-ROM 4.7 GB (DVD-5), 8.54 GB (DVD-9), 9.4 GB (DVD-10),
3.95 GB (DVD-R version 1.0), 4.7 GB (DVD-R
version 2.0), 4.7 GB (DVD-RW version 1.0 and 1.1),
4.7 GB (DVD+RW), 4.7G (DVD+R), 8.5 GB (DVD+R
DL)
CD-ROM 540 MB (Mode 1, 12 cm), 640 MB (Mode 2, 12 cm),
700 MB (80 minimum CD-R and CD-RW), 180 MB
(8 cm)
QuickSpecs
HP Compaq Business Desktop dx6120 Series
Technical Specifications - Optical Storage
DA - 12243 Worldwide — Version 21 — May 25, 2007 Page 45
