LSI PCIe x1 56K
International
SoftModem
Data Transmission
Technology speeds: 56,000 Kbps maximum downstream data,
controllerless
NOTE:
56 Kbps technology refers to download speeds only and
requires compatible modems at server sites. Other conditions may limit
modem speed. FCC limitations allow a maximum of 53 Kbps during
download transmissions.
Data Speeds
(Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/
16,800/14,400/12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards
ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell
212A, and Bell 103
Fax Speeds
14,400/12,000/9,600/7,200/4,800/2,400/1,200/300 b/s
Fax Mode Capabilities
ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Error Correction and
Data Compression
V.44, 42bis, V.42 and MNP2-5
Power Management
PCI Bus Power Management Interface Specification (PCI-PM) Revision
1.2, Appendix A. D0, D3hot, and D3cold. Wake on Ring state when in
D3cold. If the power management event (PME) feature is enabled in
D3cold, a modem can wake the system via WAKE# (WAKEN) or
beacon. Meets PCI Express 1.1 standard.
Upgradeability
Driver upgradeable for future enhancements
Video
ITU-T V.80 video ready interface
Other
TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel
16550a UART-compatible interface
Optional ring wakeup signal
Operating
Temperature
32° to 158° F (0° to 70° C)
Operating Humidity
20% to 90%, non-condensing
Power
Requires a 3.3-V auxiliary power rail on PCI express bus
Uses only one PCI express load (i.e., one grant/request pair), one
shared IRQ, one electrical load
Chipset
LSI SV92EX - Integrated PCI interface with 3.3-V tolerant buffers and
CardBus support
Dimensions
(L X H)
Complies with PCI express low profile specifications-6.7 x 2.3 in (17.0 x
5.8 cm) and supports high- and low-profile brackets
Connection
Single RJ-11 connector
Other Features
Digital line protection, call progress monitoring via on-board piezo
device, support for high profile and low profile brackets, PnP ID support
Safety
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950
(TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO,
DEMKO, SEMKO, CE mark
EMC
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN
61000-4-6, EN 61000-4-8
Telecom
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Other
The SV92EX device is packaged in a 32-pin micro leadless chip carrier
(MLCC). The SV92EX is fully compliant with the PCI Express revision
1.1 specification. WHQL approved; ASPM compliant.
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications - Communications
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010
Page 31
