10,000 RPM Serial ATA
Hard Drives
160 GB
Capacity
160,041,885,696 bytes
Height
1 in (2.54 cm)
Width
Media diameter: 3.0 in (7.62 cm)
Physical size: 4 in (10.2 cm)
Interface
Serial ATA (1.5 Gb/s), Native Command Queuing
enabled
Synchronous Transfer
Rate
(Maximum)
Up to 3.0 Gb/s
Cache
16 Mbytes
Seek Time
(typical
reads, includes
controller overhead,
including settling)
Single Track
0.3 ms
Average
4.6 ms
Full-Stroke
10.2 ms
Rotational Speed
10,000 rpm
Logical Blocks
312,581,808
Operating
Temperature
41° to 131° F (5° to 55° C)
Solid State Drive
64 GB
Capacity
64 GB
NAND Flash Memory
Multi Level Cell (MLC) with wear leveling controller
Interface type
SATA 3Gb/sec
Dimensions-external
(W x H x D)
2.74 x 0.37 x 4 in (6.98 x 0.95 x 10.2 cm)
Weight
0.14 lb (65 g)
Internal transfer rate
Write speed
Up to 220 MB/s
Read speed
Up to 120 MB/s
Host transfer rate
Ultra DMA mode
Up to 150 MB/s
Power
DC power requirement
5 VDC 5%-100 mV ripple p-
p
Total power
consumption
<1.12Watt
Environmental
(all conditions, non-
condensing)
Temperature
(operating)
32° to 158° F (0° to 70° C)
Relative Humidity
(operating)
5% to 95%
Maximum Wet Bulb
Temperature
(operating)
84° F (29° C)
Regulations
UL, CSA, EN 60950-2000, CISPR Pub 22 Class B,
CNS 13438, AS/NZS CISPR 22:2002 Class B, R1113
and C1172 Class B
NOTE:
For solid state disk drives, GB means 1 billion bytes. 16GB is the
unformatted capacity of this drive before a portion of the drive is reserved for
flash management features. Actual capacity varies by content and will be less
than 15.8GB.
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications - Hard Drives
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010
Page 44
