Switch type
Light force micro-switch
Switch life
1 million operations
Mechanical life
Minimum 200,000 revolutions
Regulatory approvals
Compliant
UL, CSA, FCC, CE Mark, TUV, TUV GS,
VCCI, BSMI, C-Tick, MIC
HP USB Optical Scroll
Mouse
Dimensions
(H x L x W)
1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm)
Weight
0.27 lb (0.12 kg)
Cable length
72.8 in (185 cm)
System requirements
Microsoft Windows 95, 98, 2000, Me, XP and Vista
Available USB port
HP USB 2-Button Laser
Mouse
Scroll Wheel
24
Maximum Rotation
Speed
48 rats/sec
Switch Type
wheel
Switch Life
Button - 3,000,000
Wheel - 1,000,000 times
Tilt switch - 500,000 times
Environmental
Operating
Temperature
32° to 104° F (0° to 40° C)
Non-operating
Temperature
-4° to 140° F (-20° to 60° C)
Operating Humidity
10% to 90% (non-condensing at ambient)
Non-operating
Humidity
20% to 80% (non-condensing at ambient)
Operating Shock
40 g, six surfaces
Non-operating Shock
80 g, six surfaces
Operating Vibration
2-g peak acceleration
Non-operating
Vibration
4-g peak acceleration
Electrical
Operating Voltage
+ 5VDC ± 5%
Power Consumption
MTBF
> 150,000 hrs
ESD
IEC-61000-4-2 criteria B, Contact discharge:
+/- 4kV, Air discharge: +/- 8kV
EMI-RFI
FCC Class B
PC98
PC 99 Compliant
Mechanical
Resolution
800dpi
Tracking Speed
25 cm/sec
Acceleration
0.5mm
Switch Actuation
0.6N (60gf)
Switch Life
Button - 3,000,000
Wheel - 1,000,000 times
Tilt switch - 500,000 times
Cable Length
1850mm
PC98-99
PC99 compliant
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications - Input/Output Devices
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010
Page 49
