Audio output Line-Out 0.7 VRMS
Signal-to-Noise Ratio 74 dB
Channel Separation 65 dB
Environmental
conditions (operating -
non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 90%
Maximum Wet Bulb
Temperature
86° F (30° C)
HP Slim DVD-ROM
Drive
Height 12.7mm
Orientation Either horizontal or vertical
Interface type SATA/ATAPI
Dimensions (W x H x D) 5.0 x 0.5 x 5.0 in (128 x 13.6 x 129 mm)
Weight (max) 0.42 lb (190 g)
Read speeds DVD+R/-R/+RW/
-RW/+R DL /-R DL
Up to 4X
DVD-ROM Up to 8X
CD-ROM, CD-R Up to 24X
CD-RW Up to 24X
Access time
(typical reads, including
settling)
Random DVD DVD: < 140 ms (typical), CD: < 125 ms
(typical)
Random CD DVD: < 250 ms (seek), CD: < 210 ms (seek)
Data Transfer Modes ATA PIO mode 4 (16.7 MB/s); ATA Multi-word
DMA mode 2 (16.7 MB/s)
Power Source Four-pin, DC power receptacle
DC Power
Requirement
5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC - <1000 mA typical, < 1600 mA
maximum
Total Drive Power
(standby mode)
< 2.5 Watt
Audio output Line-Out 0.7 VRMS
Signal-to-Noise Ratio 74 dB
Channel Separation 65 dB
Environmental (all
conditions non-
condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 5% to 85%
Maximum Wet Bulb
Temperature
(operating)
86° F (30° C)
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications - Optical Storage
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 55

HP Compaq ELITE 8000 Specifications

General

Chipset	Intel Q45 Express
Memory	Up to 16 GB DDR3 SDRAM
Audio	Integrated High Definition Audio
Network	Integrated Intel 82567LM Gigabit Network Connection
Power Supply	240W or 320W
Form Factor	Small Form Factor (SFF), Convertible Minitower (CMT)
Processor	Intel Core 2 Duo, Intel Core 2 Quad
Processor Speed	Up to 3.33 GHz
Storage	Up to 1 TB
Graphics	Integrated Intel Graphics Media Accelerator 4500
Optical Drive	DVD-ROM
Ports	USB 2.0, VGA, DisplayPort, serial, parallel, PS/2
Operating System	Windows 7, Windows Vista
