HP Compaq LE1711 User Manual

Icon Main Menu Submenu Description
DDC/CI Support Allows the computer to control some OSD menu
features such as brightness, contrast and color
temperature. Set to:
●
On
●
Off
The factory default is On.
Bezel Power LED Turns off the power LED on the front panel of the
monitor. The factory default is On.
Sleep Timer Provides the timer adjustment menu options:
●
Set Current Time—sets the current time in hours
and minutes
●
Set Sleep Time—sets the time you want to place
the monitor in sleep mode
●
Set on Time—sets the time you want the monitor
to wake up from sleep mode
●
Timer—sets the Sleep Timer feature On or Off.
The default setting is Off.
●
Sleep Now—immediately sets the monitor to
enter sleep mode
Language Selects the language in which the OSD menu is
displayed. The factory default is English.
Information Selects and displays important information about the
monitor.
Current Settings Provides the current input video mode.
Recommended
Settings
Provides the recommended resolution mode and
refresh rate for the monitor.
Serial Number Reports the serial number of the monitor. The serial
number is needed if contacting HP technical support.
FW Version Reports the firmware version of the monitor.
Backlight Hours Reports the total hours of backlight operation.
Service Support http://www.hp.com/support
Factory Reset Returns all OSD menu settings and DDC/CI controls
to the factory default settings, except the Language.
Exit Exits the OSD menu screen.
Optimizing Digital Conversion
Two controls in the on-screen display can be adjusted to improve image performance: Clock and Clock
Phase.
Table 4-2 OSD Menu (continued)
18 Chapter 4 Operating the Monitor

HP Compaq LE1711 Specifications

General

Package depth	472 mm
Package width	448 mm
Package height	121 mm
Package weight	5100 g
3D	No
Panel type	TN
Pixel pitch	0.264 x 0.264 mm
Aspect ratio	5:4
Display surface	Matt
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Display technology	LED
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1280 x 960, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Plug and Play	Yes
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), DUT, ENG, ESP, FRE, ITA
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
DVI-D ports quantity	0
Current rating	0.50 A
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (standby)	2 W
Power consumption (typical)	19 W
Product color	Black, Silver
Country of origin	China

Weight and Dimensions

Depth (with stand)	206 mm
Height (with stand)	386 mm
Depth (without stand)	57 mm
Width (without stand)	377 mm
Height (without stand)	316 mm
Weight (without stand)	3900 g
