Remove the keyboard:
1.
Remove the three Phillips PM2.0×6.0 screws that secure the keyboard to the computer.
2.
Turn the computer right-side up, with the front toward you.
3.
Open the computer as far as it will open.
4. Lift the rear edge of the keyboard (1) until it rests at an angle.
5. Slide the keyboard (2) back until the keyboard cable and connector are accessible.
6. Release the zero insertion force (ZIF) connector (3) to which the keyboard cable is attached, and
then disconnect the keyboard cable (4) from the system board.
7.
Remove the keyboard.
54 Chapter 4 Removal and replacement procedures
