HP Compaq Mini CQ10 Maintenance And Service Guide

Item Component Spare part number
For use only with non-Beats Edition computer models equipped with an Intel Atom
N2600 1.60-GHz processor, but not WWAN capability (1.0-MB L2 cache,
dual core, 3.5 W)
676909-001
(6) Heat sink (includes replacement thermal material) 651898-001
(7) Fan 651897-001
(8) Power connector cable 656095-001
(9) Battery:
6-cell, 55-Wh, 2.55-Ah, Li-ion battery 646757-001
3-cell, 28-Wh, 2.55-Ah, Li-ion battery 646755-001
(10) Base enclosure:
For use only with Beats Edition computer models 650710-001
For use only with non-Beats Edition computer models 663675-001
(11) 2-GB memory module (PC3, 10600, 1333-MHz): 621565-001
(12) WWAN module:
HP hs2340 HSPA+ Mobile Broadband Module 632155-001
HP lc2000 HSPA Mobile Broadband Module 612599-001
HP lc2010 HSPA Mobile Broadband Module 612600-001
(13) RTC battery 599516-001
(14) WLAN module:
Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter 655795-001
Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0
Combo Adapter
657325-001
Intel Centrino Advanced-N 6230 WLAN module 631956-001
Ralink 5390GN 802.11b/g/n 1×1 WiFi Adapter 630703-001
(15) Hard drive (2.5-in, 7.0-mm, SATA; does not include hard drive bracket, hard drive connector cable, hard drive
rubber isolators, screws):
500-GB, 5400-rpm 634932-001
320-GB, 5400-rpm 645193-001
250-GB, 5400-rpm 645191-001
Hard Drive Hardware Kit (not illustrated, includes hard drive bracket, hard drive
connector cable, hard drive rubber isolators, and screws)
664913-001
(16) Service cover:
Service cover in black finish for use only on Compaq Mini CQ10 and HP Mini 110
computer models
663676-001
Service cover in charcoal finish for use only on HP Mini 210 computer models 650727-001
24 Chapter 3 Illustrated parts catalog
