HP Compaq Mini CQ10 Maintenance And Service Guide

The service cover is available using the following spare part numbers:
●
663676-001—In black finish for use only on Compaq Mini CQ10 and HP Mini 110
computer models
●
650727-001—In charcoal finish for use only on HP Mini 210 computer models
●
650732-001—In crimson red finish for use only on HP Mini 210 computer models
●
650731-001—In luminous rose for use only on HP Mini 210 computer models
●
650728-001—In ocean drive for use only on HP Mini 210 computer models
●
654203-001—In sweet purple finish for use only on HP Mini 210 computer models
3. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The #1 WLAN antenna cable is connected to the WLAN module “Main” terminal.
The #2 WLAN antenna cable is connected to the WLAN module “Aux” terminal.
4. Remove the Phillips PM2.0×3.0 screw (2) that secures the WLAN module to the system board.
(The WLAN module tilts up.)
Component replacement procedures
53
