Abbreviation Component
CL1 Duplex re-pickup clutch (duplex models only)
SL2 Duplex reverse solenoid (duplex models only)
SL3 Multipurpose tray pickup solenoid
SL4 Cassette pickup solenoid
Figure 5-29 Three main units of the pickup, feed, and delivery system
Fuser/delivery block
Duplex block
Y
M
C
K
Table 5-13 Motors and solenoids for the pickup, feed, and delivery system (continued)
138 Chapter 5 Theory of operation ENWW
