Fuser motor
Before proceeding, remove the following components:
●
Formatter. See
Formatter PCA on page 175.
●
Right-rear cover. See
Right-rear cover on page 198.
●
Left cover. See
Left cover on page 200.
●
Rear cover and upper-rear cover. See
Rear cover and upper-rear cover on page 209.
NOTE: It is not necessary to separate the upper-rear cover from the rear cover to remove the
fuser motor.
●
Interconnect board (ICB). See
Interconnect board (ICB) on page 238.
TIP: For internal product access, you can remove the ICB and the low-voltage power supply as
a single component.
●
DC controller PCA. See
DC controller PCA and tray on page 240.
●
Low-voltage power supply. See
Low-voltage power supply on page 243.
●
High-voltage power supply upper. See
High-voltage power supply upper (HVPS-T) on page 279.
NOTE: The terms fusing and fixing are synonymous.
ENWW Internal assemblies 285
