3. Slide the hooks at the top of the stand into the slots on the rear of the monitor panel (1) then snap
the latches on the stand into the latch holes on the monitor (2).
Figure 3-2 Installing the Monitor Stand
Rear Components
Figure 3-3 Rear Components
Component Function
1 AC Power Connector Connects the AC power cord to the monitor.
2 Audio Connects the audio cable to the monitor.
3 VGA Connects the VGA cable to the monitor.
ENWW Rear Components 5
