HP D5259A - Pavilion M70 - 17" CRT Display User Manual

FACTORY MODES
FACTORY MODESFACTORY MODES
FACTORY MODES
Mode No.
Mode No.Mode No.
Mode No. 6
66
67
77
78
88
89
99
910
1010
10 Unit
UnitUnit
Unit
Resolution
Horizontal Frequency
(A) Horizontal
(B) Horizontal Pulse Width
(C) Horizontal Back Porch
(D) Horizontal Active Area
(E) Horizontal Front Porch
(F) H. Sync. Polarity
Vertical Frequency
(O) Vertical Period
(P) Vertical Pulse Width
(Q) Vertical Back Porch
(R) Vertical Active Area
(S) Vertical Front Porch
(T) V. Sync. Polarity
(U) Interlaced
800 x 600
46.875
21.333
1.616
3.232
16.162
0.323
+
75.000
13.333
0.064
0.448
12.800
0.021
+
No
1024 x 768
48.363
20.677
2.092
2.462
15.754
0.369
–
60.00
16.666
0.124
0.600
15.88
0.062
–
No
800 x 600
53.674
18.631
1.138
2.702
14.222
0.702
–
85.061
11.756
0.056
0.503
11.179
0.019
+
No
1024 x 768
56.476
17.707
1.813
1.92
13.653
0.521
–
70.069
14.272
0.106
0.513
13.599
0.054
–
No
1024 x 768
68.677
14.561
1.013
2.2
10.836
0.471
+
85
11.764
0.044
0.524
11.182
0.014
+
No
KHz
usec
usec
usec
usec
usec
Hz
msec
msec
msec
msec
msec
20
2020
20
v
vv
v70s Monitor Guide
70s Monitor Guide70s Monitor Guide
70s Monitor Guide
