HP DesignJet 100 Technical Specifications

hp designjet
100 printer
technical specifications
print technology HP Thermal Inkjet
printhead nozzles 300
print speed A4 draft: 11 pages per minute
A1 draft: 90 seconds per page
maximum speed best quality
colour images 25 sq m/hr 1.6 sq m/hr
maximum resolution 1200 x 600 dpi.
operating systems compatibility Microsoft
®
Windows
®
95, 98, Me, NT 4.0, 2000 and XP.
minimum system requirements Microsoft
®
Windows
®
95/98, Pentium
®
I, 133 MHz, 48 MB RAM, 300 MB available hard disk space;
Windows NT, Pentium II, 300 MHz, 64 MB RAM, 400 MB available hard disk space; Windows 2000,
Pentium II, 300 MHz, 128 MB RAM, 400 MB available hard disk space; Windows XP, Pentium III, 733 MHz,
128 MB RAM, 400 MB available hard disk space.
recommended system requirements Microsoft
®
Windows
®
95/98 Pentium
®
1, 133MHz, 64 MB RAM, 320 MB available hard disk space;
Windows NT, Pentium III, 733 MHz, 128 MB RAM, 2 GB available hard disk space; Windows 2000,
Pentium III, 733 MHz, 256 MB RAM, 2 GB available hard disk space; Windows XP, Pentium 4, 1 GHz,
256 MB RAM, 2 GB available hard disk space.
memory 16 MB
standard printer languages HP PCL 3 GUI.
standard media sizes A1, A2, A3, A4, B2, B3, B4, A2 metric oversize, A/B/C/D (English architectural), envelopes.
custom media sizes 76 x 152 mm to 625 x 1625 mm
maximum length of sheet media 1625 mm
media types Paper (plain, coated, natural tracing, two-sided brochure, photo, heavyweight), transparencies, vellum,
translucent bond.
power requirements Input voltage 100 to 240 VAC autoranging, 50/60 Hz, 2A max.
power supply type Built-in Universal Power Supply.
power consumption 65 watts maximum.
interface and connectivity Standard: USB 1.1 (Microsoft
®
Windows
®
98 2nd edition, Me, 2000 and XP) USB 2.0 compliant Centronics
Parallel IEEE-1284 compliant (ECP), 1 EIO slot.
Optional: HP Jetdirect 615n, HP Jetdirect 610n, HP Jetdirect 600n, HP Jetdirect 680n, HP Jetdirect Token
Ring, HP Jetdirect 175x, HP Jetdirect 310x, HP Jetdirect 380x.
drivers included HP PCL 3 GUI Windows driver, Microsoft
®
Windows
®
95, 98, Me, NT 4.0, 2000 and XP drivers, AutoCAD
™
13 and 14 drivers, USB and ECP drivers.
software included HP maintenance tool.
dimensions (w x d x h) Out of package: 1042 x 400 x 220 mm.
product weight Out of package: 21 kg.
operating environment Environmental ranges: Operating temperature: 5 to 40° C. Operating humidity: 20 to 80% RH.
Recommended operating humidity: 25 to 75% RH. Recommended operating temperature: 15 to 30° C.
Storage temperature: -20 to 55° C. Storage humidity: 20 to 80% RH. Noise level per ISO 9296:
Sound power: 6.2 B(A), Sound pressure: 50 dB(A).
ENERGY STAR Yes
certifications Compliant with requirements for Class B ITE products (Class A when connected to LAN cables), EU (EMC
Directive), USA (FCC rules), Canada (DOC), Australia (ACA), New Zealand (MoC), China (CCC), Japan
(VCCI), Class A for Korea (MIC), Taiwan (BSMI). Regulatory standards: ITE product compliance, EU LVD, CSA
certified for US and Canada, Mexico NOM-1-NYCE, Argentina IRAM, China CCC, Singapore PSB, Russia
GOST, Poland PCBC, Korea KTL
warranty 1 year warranty includes phone support from Monday to Friday at business hours and express exchange in
most countries. Some countries may have slightly different support delivery methods depending on local
infrastructure. With HP Support Packs you can extend your warranty up to 3 years.
ordering information
c7796a hp designjet 100 printer
accessories
q1246a hp stand
supplies
c4844ae hp no.10 large black ink
cartridge (69 ml)
c4836ae hp no.11 cyan ink
cartridge (28 ml)
c4837ae hp no.11 magenta ink
cartridge (28 ml)
c4838ae hp no. 11 yellow ink
cartridge (28 ml)
c4810a hp no.11 black printhead
c4811a hp no.11 cyan printhead
c4812a hp no.11 magenta printhead
c4813a hp no.11 yellow printhead
media
q1963a hp proofing paper, glossy,
C+, 50 sheets
q1964a hp proofing paper, glossy,
D+, 50 sheets
q1967a hp proofing paper, matt,
B+, 100 sheets
q1961a hp coated paper, C+, 100 sheets
q1962a hp coated paper, D+, 100 sheets
For a complete list of printing material and
selection numbers, please refer to the
HP website at
http://www.hp.com/go/designjet
and select ‘Printing Materials’
print servers & peripheral sharing
j6057a hp jetdirect 615n Fast Ethernet
internal print server
service and support
u3423a/e hp supportpack, 3 years next
day replacement service (available in
most countries)
http://www.hp.com
http://www.hp.com/go/designjet
For more information, please call your local HP sales office or representative: Austria: 0810/006080 (local rate call), Algeria: (0)61 56 45 43,
Bahrain: 800 728, Belgium: (02) 778 34 00, Luxembourg: (+352) 263 160 34, Bulgaria: (+359) 2960 1940, Croatia and Slovenia: (+385 1) 60 60
200, Czech Republic: (00 420 2) 613 07 111(Prague), Denmark: 45991700 or 70101125, Egypt: 532 5222, Estonia: (+372) 6505 263, Finland:
(09) 88721, France: (1) 69 82 6060, Germany: 0180 532 6222 (12 Cent/min), Greece: (01) 678 96 00, Hungary: (+36) 1 382-1111, Iceland:
(354) 570 1000, Ireland: + 353 1 6158200, Israel: (972) 9 8304848, Italy: (02) 92121, Kazakhstan: +7 (3272) 980 824, Latvia: (371) 800 80 12,
Lithuania: (370) 2 787 333, Middle East: 00971 4 883 4427, Morocco (African Region): +212 22 40 47 47, Netherlands: (020) 5476666, Norway:
22 735600, Poland: infolinia 0-801 607 607 (0,29 zl + VAT/min), Portugal: (808) 206 001, Romania: (+401) 205 3300, RSA: (27)11 785 1000,
Russia: +7 (095) 797 35 00, Saudi Arabia: 800 124 4646, Slovakia: +421-2-50205611, Spain: (91) 6311600, Sweden: (08) 444 2000,
Switzerland: 0848 88 44 66, Tunisia: 71 891 222, Turkey: +90 (216) 579 71 71, UAE: 8004910, UK: 08705 474747, Ukraine: +380 44 490 61
20, Yugoslavia: +381 11 322 80 14.
The information contained in this
document is subject to change without
notice. ENERGY STAR is a U.S. registered
mark of the United States Environmental
Protection Agency. All other products
mentioned herein may be trademarks
of their respective companies.
Microsoft, Windows and MS Windows
are U.S. registered trademarks of
Microsoft Corporation.
© Copyright Hewlett-Packard 20XX
Printed in the EU XX/XX
5981-2306EEE

HP DesignJet 100 Specifications

Print Technology

print technology	HP Thermal Inkjet
printhead nozzles	300
maximum resolution	1200 x 600 dpi

Print Speed

print speed A4 draft	11 pages per minute
print speed A1 draft	90 seconds per page
colour images speed	25 sq m/hr

Power

input voltage	100 to 240 VAC
power frequency	50/60 Hz
power consumption	65 watts maximum

Memory and System Requirements

memory	16 MB
minimum system RAM for Windows 95/98	48 MB
recommended system RAM for Windows 95/98	64 MB

Operating Environment

operating temperature range	5 to 40° C
recommended operating temperature	15 to 30° C
operating humidity range	20 to 80% RH

Dimensions and Weight

dimensions (w x d x h)	1042 x 400 x 220 mm
product weight	21 kg
maximum length of sheet media	1625 mm
