HP DesignJet 130nr Parts Reference Guide

DesignJet 130n
r
HP Parts Reference Guide™
www.h
p
.com/
g
o/h
pp
arts
Other Internal Parts
Ink Delivery System
27
C7791-60129 RIDS assembly - Transports ink from the ink supply station to the printheads
Ink Supply Station
28
C7790-60089 Ink supply station assembly - Holds the ink cartridges and pumps ink out to the printheads
Spring
29
C7790-60125 Belt tensioner spring
Turnaround Assembly
30
C7791-60212 Turnaround assembly - Includes belt tensioning spring
Paper Path Parts
Cam
76
C7791-60232 Pick cam - Located on the left-side of the print mechanism
Guide
77
C7791-60202 Inner paper guide - Guides the paper through the paper path
Pivot
78
C7796-60026 Pivot assembly - Black plastic part under platten - Supports pick roller
Platen
79
C7791-60144 Print Platen - Surface that supports paper during printing
80
C7791-60220 Bypass platen assembly
Roller Assembly
81
C7791-60200 Pick roller assembly - Picks media from the input paper tray and feeds it through the paper path
82
C7791-60201 Feed roller assembly - Includes encoder disk and paper-axis motor assembly - Feeds media under the carriage
assembly
Roller Kit
83
C7791-60230 Upper paper guide roller kit (includes 8 rollers) - Helps to guide media through paper path
84
C7791-60235 Lower paper guide roller kit - Helps to guide media through paper path
Sensor
85
C7791-60229 OOPS sensor
Starwheel
86
C7791-60245 Starwheel assembly - Provides downward pressure on media as it passes through the feed rollers
Paper Tray Parts
Cam
87
C8108-67050 Drawer and spring cam - Short, spring loaded lever attached to the paper tray frame - Used to draw input tray into
position
Cover
88
C7791-60297 Paper input tray cover - Black platic cover that is placed on top of the paper input tray
Paper Trays
Tray
89
C7791-60280 Paper output tray assembly
90
C7791-60298 Paper input tray assembly - Holds paper supply for printer
Paper and Other Media
Film (Transparency)
C3834A Premium InkJet transparency film - A size (8.5 x 11-inches) - 50 sheets per package
C3835A Premium InkJet transparency film - A4 size (21.0cm x 29.7cm) - 50 sheets per package
© 2004 Hewlett-Packard 2
