HP DesignJet 130nr Parts Reference Guide

DesignJet 130n
r
HP Parts Reference Guide™
www.h
p
.com/
g
o/h
pp
arts
Paper and Other Media
Paper (Photo)
C6951A Premium plus matte InkJet photographic paper - A4 size (21.0cm x 29.7cm) - 20 sheets per package
C6979A Premium glossy photo paper (fast dry time) - A size (8.5 x 11-inches) - 50 sheets per package
C8310A Basic Photo Satin paper - 61cm (24in) x 30.5m (100ft) (USA and Asia/Pacific)
Q1420A Semi-Gloss Photo Paper - 61cm (24in) x 30.5m (100ft)
Q1785A Photo Paper - A size (8.5 x 11-inches) - 50 sheets
Q1786A Premium Plus Photo Paper - A4 size (21.0cm x 29.7cm) - 50 sheets
Paper (Semi-Glossy)
C7884A Large format proofing semi-gloss media - 33.0 cm (13in) x 48.3cm (19in)
Q2509A Semi-gloss Everyday Photo Paper - A size (8.5 x 11-inches) - 100 sheets
Q2511A Semi-gloss Everyday Photo Paper - A4 size (21.0cm x 29.7cm) - 100 sheets
Print Mechanism Parts
Belt
91
C8108-67048 Drive belt for the output mechanism assembly
Encoder
92
C8108-67051 Paper motor encoder disk - Mounts on the left end of the pivot and feedroller assembly shaft
Motor
93
C7791-60143 Carriage drive motor - Drives the carriage belt
94
C8108-67038 Paper motor assembly - Powers the drive roller
95
C8108-67040 Ramp motor assembly - Used to operate paper output rollers
Spittoon
96
C7791-60203 Ink spittoon - Holds any residual ink from the print cartridge cleaning process
Support
97
C8108-67042 Output mechanism support assembly
Roll Feed Assembly Parts
Bracket
98
C7791-60215 Rollfeed support bracket - Used in conjunction with the automatic rollfeed kit
Cutter
99
C7797-60007 Media cutter assembly
Rollfeed Assy
100
Q1247-60023 Automatic rollfeed kit
Q1247A DesignJet 100 series auto roll feed assembly - Automatically feeds paper into the plotter
Spindle
102
C7797-60008 24 inch spindle assembly
Q1264A DesignJet 100 series spindle accessory - Japan Only
Stand Parts
Adapter
104
Q1246-60011 Base adaptor kit (includes 2)
Bin
105
Q1246-60010 Paper bin assembly
Brace
106
Q1246-60008 X-brace assembly - Connects between both legs
