HP Designjet T1100

Parts and Diagrams
5-6 HP Designjet T Series — Service Manual
Center Covers (Rear)
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a Refers to the page in the Removal and Installation Chapter
a
1 Q6683-60207 Rear Tray Supports
All
All 6-43
2
Q6683-67802
Clean Out Assembly
24 inch
6-90
Q6687-67801 44 inch
3 Q5669-67801 Out Of Paper Sensor All
6-91
4
Q6683-60194
Rear Tray
T1100/
T1100p
s
/T610
24 inch
6-35
Q6687-60058 44 inch
CK837-67021
T1120/
T1120p
s
24 inch
CK839-67007 44 inch
5
Q6683-60200
Rear Cover All
24 inch
6-36
Q6687-60063 44 inch
