HP Designjet T1100

Parts and Diagrams
5-8 HP Designjet T Series — Service Manual
Right Cover
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a Refers to the page in the Removal and Installation Chapter
a
1
Q6683-60203
Right Cover (without Right Ink
Cartridge Door)
T1100/
T1100p
s
/T1120/
T1120ps
All
6-27
Q6711-60003 T610
2 Q6675-60109
Left Front Trim/Right Front Trim (Left
not shown)
All
6-19
3
Q6683-60205
Right Ink Cartridge Door
T1100/
T1100p
s
6-23
Q6711-60004 T610
Q6683-60233
T1100/
T1100p
s
/T610
CK837-67024
T1120/
T11
20p
s
