HP Designjet T1100

Parts and Diagrams
5-10 HP Designjet T Series — Service Manual
Left Cover
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a Refers to the page in the Removal and Installation Chapter
a
1 Q6683-60232 Left Ink Cartridge Door
All
All
6-25
2 Q6675-60109
Left Front Trim/Right Front Trim
(Right not shown)
6-21
3
Q6683-67003
Left Side Panel
T1100/
T1100p
s
/T1120/
T1120ps
6-30
Q6711-60005 T610
4 Q6683-60202
Left Cover (without Left Ink
Cartridge Door & Left Side Panel)
All
6-30
