HP Designjet T1100

Parts and Diagrams
5-20 HP Designjet T Series — Service Manual
Scan-Axis Assemblies (T1100/T1100ps/T610)
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a Refers to the page in the Removal and Installation Chapter
a
1
Q6683-60195
Ink Supply Tubes
T1100/
T1100p
s
/T610
24 inch
6-193
Q6687-60059 44 inch
2
Q6683-60242 Encoder Strip (including Encoder
St
rip Spring and Nut)
24 inch
6-99
Q6687-60094 44 inch
3
Q5669-60673
Belt Assembly
24 inch
6-141
Q6659-60175 44 inch
4
Q6687-60094
Trailing Cable and Carriage PCA
Cov
e
r
24 inch
6-99
Q6659-67015 44 inch
-
Q5669-60679
Encoder Strip (including Encoder
S
tr
ip Spring and Nut) - 50 units
24 inch
6-99
Q6659-60176 44 inch
