HP Designjet T1100

Parts and Diagrams
5-24 HP Designjet T Series — Service Manual
Paper Path Assemblies (Front)
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a Refers to the page in the Removal and Installation Chapter
a
1
Q6683-60196
Starwheel Assembly
All
24 inch
6-208
Q6687-60060 44 inch
2
Q6675-60042
Print Zone Overdrive
24 inch
6-210
Q6677-60018 44 inch
3 Q5669-67054 Starwheel Lifter
All
6-237
4 Q5669-60713 Cutter Assembly 6-42
5
Q5669-60701
Full Bleed Foam Kit
24 inch
6-247
Q6659-60182 44 inch
