HP Designjet T1100

HP Designjet T Series — Service Manual 5-26
Parts and Diagrams - Paper Path Assemblies (Rear)
Paper Path Assemblies (Rear)
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a Refers to the page in the Removal and Installation Chapter
a
1 Q6687-60085 Pinchwheel Assembly
All
All 6-229
2 Q6677-60019 Left Roll Guide 44 inch 6-94
3 Q6687-60082 Left Spindle Holder All 6-80
4
Q5669-60710
Spindle
24 inch
6-79
Q6687-67001 44 inch
5
Q6683-67009 Right Spindle Holder 24 inch
6-81
Q6687-67004
Right Spindle Holder (rewinder
inc
luded)
T1100/
T1100p
s
/T610
44 inch
6-87
CK839-67002
Right Spindle Holder (rewinder
inc
luded)
T1120/
T1120ps
44 inch
6-87
6 Q6675-60044 Right Roll Guide
All
All 6-95
7 Q6683-67005 Media Advance Roller 24 inch 6-223
