HP Designjet T1100

HP Designjet T Series — Service Manual 6-1
6
Removal and Installation 5
Introduction 6-3
Service Calibration Guide to Removal and Installation 6-5
Bin Assembly 6-10
Window 6-12
Covers and Trims 6
-16
Rear Tray 6-35
Rear Cover 6-36
Media Lever 6-37
Media Lever Position Sensor 6-40
Cutter Assembly 6-42
Left Rear Tray Support 6-45
Front Panel 6-47
Top Cover 6-50
Window Position Sensor 6-53
Ink Supply Tubes Support Rail (T1100/T1100ps/T610) 6-55
Ink Supply Tubes Support Rail (T1120/T1120ps) 6-59
Service Station (T1100/T1100ps/T610) 6-61
Service Station (T1120/T1120ps) 6-65
Drop Detector 6-69
Aerosol Fan Assembly (T1100, T1100ps, T610 ONLY) 6-71
PrintMech PCA (T1100, T1100ps, T610 ONLY) 6-73
Pen to Paper Space (PPS) Solenoid (T1100/T1100ps/T610) 6-75
Pen to Paper Space (PPS) Solenoid (T1120/T1120ps) 6-77
Spindle 6-79
Left Spindle Holder 6-80
Right Spindle Holder (24” ONLY) 6-81
Right Spindle Holder and Rew
inder (T1120/T1120ps) 6-87
Right Spindle Holder and Rew
inder (T1120/T1120ps) 6-87
Clean Out Assembly 6-90
Out Of Paper Sensor 6-91
Left Roll Guide 6-94
Right Roll Guide 6-95
Encoder Strip, spring and attachment nut (T1100/T1100ps/T610) 6-96
Encoder Strip, spring and attachment nut (T1120/T1120ps) 6-99
Encoder Strip 6-101
Trailing Cable (T1100/T1100ps/T610) 6-102
Trailing Cable (T1120/T1120ps) 6-109
Carriage Assembly (T1100/T1100ps/T610) 6-116
Carriage Assembly (T1120/T1120ps) 6-127
Carriage Rear Bushing 6-137
Left and Right Bumpers (T1120/T1120ps ONLY) 6-139
Belt Assembly 6-141
Scan-Axis Motor (T1100/T1100ps/T610) 6-142
Scan-Axis Motor (T1120/T1120ps) 6-146
Carriage Rail Oiler 6-150
Line Sensor (T1100/T1100ps/T610) 6-152
Line Sensor (T1120/T1120ps) 6-157
Carriage Cover and Carriage Latch (T1100/T1100ps/T610) 6-163
Carriage Cover and Carriage Latch (T1120/T1120ps) 6-168
