HP Designjet T1100

6-4 HP Designjet T Series — Service Manual
Removal and Installation
Required Tools
All the special tools and equipment required to disassemble, service and repair the Printer are
provided in the Toolkit P/N Q6683-67001. Some tools can be ordered seperately from the toolkit.
See
Tool Kits on page 5-28.
The Toolkit contains the following tools:
T Series P/N Q6683-67001
Description/Comments HP Part Number
13 mm Combination Spanner Q6675-67011
Alcohol Q6675-60091
Allen Key #2 Q6675-60041
Cleaning Cloth 9300-2531
Flex Contacts Cleaning Support Q1271-40384
Lubricant Oil Q6675-60090
Media Driver Adjustment Tool Q6675-67009
Handle for Media Driver Tool Support Q6675-67010
Spanner Q6675-67011
Oil Dispenser Q6675-60062
Manual Pinch Arm Alignment Tool Q5669-20595
Spring Insertion Tool Q5669-20594
Protective Plastic Gloves Q6675-60035
Screwdriver 8710-2456
Tweezers Q6675-60037
T Series Cleaning Assembly
C6071-60218
You will also need the following standard hand tools:
Standard Tool Requirements
Description/Comments Size
Long Torx Screwdriver 1/4 inch drive
Torx Bit (75 mm) 8
10
15
20
Philips Screwdriver 1
Pliers N/A
Snips N/A
Pipe Spanner 5.5 mm
Flat Bladed Screwdriver N/A
