HP Designjet T1100

HP Designjet T Series — Service Manual 6-17
Removal and Installation - Media Output Assembly
Media Output Assembly
Removal
1. Remove the Front Cover on page 6-16.
2. Remove four T-15 screws that secure the
Media Output Assembly to the printer.
3. Release the four attachment clips.
4. Lift the front of the Media Output
Assembly.
Switch off the printer and remove the power cable.
