HP Designjet T1100

6-30 HP Designjet T Series — Service Manual
Removal and Installation
Left Cover
Removal
1. Remove the Front Cover on page 6-16
2. Open the Ink Cartridge Door.
3. Remove the Ink Cartridges from the Printer.
The illustration shows the T1100 which has
six Ink Cartridges.
4. Press the clip to release the Left Cover
Finishing Panel.
Switch off the printer and remove the power cable.
