HP Designjet T1100

6-36 HP Designjet T Series — Service Manual
Removal and Installation
Rear Cover
Removal
1. Remove the Rear Tray on page 6-35.
2. Re
move the Right Cover on page 6-27.
3. Re
move the Left Cover on page 6-30.
4. Remove ten T-15 screws that secure the
Rear Cover to the printer.
5. Remove the Rear Cover from the printer.
Switch off the printer and remove the power cable.
