HP Designjet T1100

HP Designjet T Series — Service Manual 6-69
Removal and Installation - Drop Detector
Drop Detector
Removal
1. Remove the Right Cover on page 6-27.
2. R
emove the Service station. See Service
Station (T1100/T1100ps/T610) on page
6-61 or Service Station (T1120/T1120ps)
on page 6-65 depending on the model.
3. Unroute the Drop Detector ribbon cable
from the Service Station cable clamps.
4. Remove the T-15 screw that secures the
Drop Detector to the Service Station.
Switch off the printer and remove the power cable.
