HP Designjet T1100

HP Designjet T Series — Service Manual 6-79
Removal and Installation - Spindle
Spindle
Removal
1. Pull the left end of the Spindle (viewed from
the front of the printer) out of the Left
Spindle Holder.
2. Lift the Spindle out of the printer towards
the left (viewed from the front of the
printer).
Switch off the printer and remove the power cable.
