HP Designjet T Series — Service Manual 6-89
Removal and Installation - Right Spindle Holder and Rewinder (T1120/T1120ps)
Installation
1. Take note of the two clips that fit to the
printer.
2. Make sure the two clips fit correctly to the
printer.
3. A correctly attached Right Spindle Holder
(rewinder included) looks like this (shown
from above).
When you finish installing or replacing this component, you must perform the
necessary Service Calibrations. To find which calibrations you must perform,
see Service Calibration Guide to Removal and Installation
on page 6-5.
Make sure you carry out the following actions during the installation of the
Right Spindle Holder (rewinder included)
View shown from above.
