HP Designjet T Series — Service Manual 6-161
Removal and Installation - Line Sensor (T1120/T1120ps)
17. Disconnect the Line Sensor electrical
connection from the Carriage PCA.
18. Carefully unroute the Line Sensor cable
from the Carriage Assembly.
19. Remove one T-10 screw that secures the
Line Sensor to the Carriage Assembly.
To Next Page
