HP Designjet T1100

HP Designjet T Series — Service Manual 6-193
Removal and Installation - Ink Supply Tubes (T1120/T1120ps)
Ink Supply Tubes (T1120/T1120ps)
Removal
1. Remove the Right Cover on page 6-27.
2. Re
move the Left Cover on page 6-30.
3. Re
move the Front Panel on page 6-47.
4. Re
move the Top Cover on page 6-50.
5. Open the Carriage Cover.
6. Remove all the Printheads.
Switch off the printer and remove the power cable.
