6 Specifications
Computer specifications
Metric U.S.
Dimensions
Height (front to back) 2.60 to 3.90 cm 1.02 to 1.54 in
Width 33.40 cm 13.15 in
Depth 23.70 cm 9.33 in
Weight (with optical drive, hard drive, and battery) 2.49 kg 5.49 lbs
Input power
Operating voltage 18.5 V dc —19.0 V dc
Operating current 3.5 A or 4.74 A
Temperature
Operating (not writing to optical disc) 0°C to 35°C 32°F to 95°F
Operating (writing to optical disc) 5°C to 35°C 41°F to 95°F
Nonoperating -20°C to 60°C -4°F to 140°F
Relative humidity
Operating 10% to 90%
Nonoperating 5% to 95%
Maximum altitude (unpressurized)
Operating (14.7 to 10.1 psia) -15 m to 3,048 m -50 ft to 10,000 ft
Nonoperating (14.7 to 4.4 psia) -15 m to 12,192 m -50 ft to 40,000 ft
Shock
Operating 125 g, 2 ms, half-sine
Nonoperating 200 g, 2 ms, half-sine
Random vibration
Operating 0.75 g zero-to-peak, 10 Hz to 500 Hz, 0.25 oct/min sweep rate
130 Chapter 6 Specifications
