NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea
level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be
limited by the type and number of options installed.
Socket LGA775 industry standard Micro ATX form factor
Processor
• Socket T; LGA775
• Support single Intel Core 2 Duo,Pentium Dual Core, Pentium D ,
Celeron D ,Celeron Conroe-L
Chipset
• Intel 945GZ Express
• Intel ICH7
Super I/O
• ITE IT8718
Front Side Bus Frequency
• 533/800MHz
Memory
• PC4200/5300 DDRII SDRAM
• 2 x DIMM slots
• Support for single or dual-channel configurations
Clock Generator
• Cypress CY28411
Integrated Graphics
• Intel Graphics Media Accelerator (GMA) 950
Audio
• Realtek ALC883 8 channel High definition audio
LAN
• Integrated Realtek 10/100/1000 ( 8110SC ) network controller
IDE
• Support all PIO modes
• 1 x IDE ports support up to 2 devices
• Support Ultra ATA 33/66/100 ( no ODD is approved on this
product)
SATA
• Four Serial ATA interfaces support data transfer rates up to 3.0
Gb/s
Expansion Slots
• 2 x PCI 2.2 slots
• 1 x PCI Express x1 slot
BIOS
• 4Mbit flash EEPROM
Manageability
• WfM 2.0, SMBus, DMI 2.0, WOL, PXE
Industrial Standard
• PCI 2.2 compliant
• USB 2.0
System Board
Rear Side I/O Ports
• 1 x PS/2 keyboard port
